Digital Signage

PNM401 40" Class Professional Display System; Built-in SoC (System on a Chip) Controller

40" Class (39.5" diagonal) Professional LCD Monitors

Built-in SoC controller with Android™ OS 4.4 & Arm® Cortex®-A17 1.8Ghz Quad Core Processor

Intel® Mini-OPS Expansion Slot supports the optional PNZB03H HDBaseT™ 2.0, PN-ZB03W Wireless Expansion & PNZB03AO Computing Boards

Optional PNZW01 Wireless Adapter

Landscape, Portrait, Face-up, Face-down Operation

Built-in 7W per Channel Stereo Audio System

3-Year Limited Warranty

450 cd/m2 Brightness; 5,000:1 Contrast Ratio

Brilliant High Definition (1920 x 1080) LED Edge Lit Display

Crestron Connected™ Compatibility

Engineered for 24/7 Use

A standalone signage solution with the flexibility and expandability to support various applications and usage styles. Thanks to its built-in SoC (System on a Chip) controller, the 50" Class (49.5" diagonal) PNM501 and 40" Class (39.5" diagonal) PNM401 monitors deliver out-of-the-box digital signage solutions even without external devices such as PCs. What’s more, the PNM501/M401 monitors come standard with original software for simple content distribution. The PNM501/M401 monitors offer versatile solutions for a wide range of digital signage applications.

Built-in SoC (System on a Chip)
The PNM501/M401 monitors has a powerful integrated SoC controller driven by the Arm® Cortex®-A17 quad core processor (max. 1.8 GHz) with 2 GB memory and 8 GB storage. It integrates Android™ OS (4.4) and comes pre-installed with several types of signage support software. This means the PNM501/M401 monitors are ready to display signage right out-of-the-box, even without a PC. It is also compatible with various third-party Android apps, which further expands the usability.

Excellent Image Quality
Thanks to its 1,920 (H) x 1,080 (V)-pixel resolution, the PNM501/M401 monitors express all of the detail and visual impact of your selected full-HD content. A brightness of 450 cd/m2 supports these LCD monitors.

Flexible Settings
Whether in a landscape or portrait orientation, the PNM501/M401 monitors can be installed face-up, face-down, or tilted forward or backward at an angle of up-to 90 degrees. Designed for easy hanging installation, they can be suspended from four corners of the rear housing with wires. Such fl¬exibility gives you more freedom to meet today’s demanding signage needs.

DisplayPort™ Daisy Chain
Multiple PNM501/M401 monitors can be set-up in a daisy chain configuration by connecting between the DisplayPort terminals, so you can display the same content simultaneously on all screens.

24-Hour Daily Operation
The PNM501/M401 monitors support 24/7 operation, bringing reliable daily performance to retail, office, and many other locations.

Wireless Connectivity (option)
An optional Wireless Board (PNZB03W) allows up to 10 devices—including Mac or Windows® computers, smartphones, and tablets—to connect to the PNM501/M401 monitors simultaneously without any cable hassles. You can display the content of one device on the whole screen, or you can display the content from up-to four devices in a 2 x 2 split screen. This wireless collaboration is a great way to enhance productivity in the workplace.

Description Operating system Type Action
Product Brochure N/A
Brochure
Product Specification Sheet N/A
Specification Sheet
Software to distribute digital signage system using LCD monitors Windows 7/8.1/10 (32-bit or 64-bit)
Software
Content Distributor is used to build an electronic signage system using LCD monitors - ver. 1.3.2.36 Windows 7/8.1/10 (32-bit or 64-bit)
Software
Operation Manual for PNB and PNM series Operation Manuals
